1. Energy Saving 57% energy-savings (Varies according to model.)

The employment of compressor inverter control has realized energy-savings in low loading. In addition,the adoption of an electronic expansion valve has made it possible to exert the maximum cooling capacity in every operating condition, and realized energy-savings even in 100% loading.

2. “Visual image of energy-savings”

Operation, Enagy saveing Indicator

3. The medium working temperature range has been expanded.

Expanded applicable temperature range to 5℃~35℃

4. MATSUI’s unique hot-gas bypass control

The machine is controlled by an inverter at and above 30Hz and, when the machine is used with a frequency lower than that, either energy-saving operation or high-accuracy operation can be selected.

5. Stable performance

Condenser is a double tube type.
For this reason, durability is improving to the foul cooling water.

6. Multi-functions

External communication function, external starting, the alarm output, and the warning buzzer were also made standard equipment.
