• NOTICE: Available until 2020.12.31 (substitute: AZ201)
• Thermoplastic enclosure
• Max. length of the sensor chain 200 m
• Self-monitoring series-wiring of 31 sensors
• 3 LEDs to show operating conditions
• Sensor technology permits an offset between actuator and interlock of ± 5 mm vertically and ± 3 mm horizontally
• Intelligent diagnosis

Compare



  Product type description Design of electrical connection Serial diagnostics (Y/N)
Actuator - -
AZ 200ST2-T-1P2P Connector M12, 8-pole No
AZ 200SK-T-1P2P Screw connection No
AZ 200CC-T-1P2P Spring pulley connection No
AZ 200CC-T-SD2P Spring pulley connection Yes
MS-AZ 200ST-T-1P2P-2568 Connector M23, 12-pole No
AZ 200SK-T-SD2P Screw connection Yes
AZ 200ST2-T-SD2P Connector M12, 8-pole Yes
