Đại lý AMPTRON Vietnam,BỘ CHUYỂN DÒNG ĐIỆN T25-W30 AMPTRON,AMPTRON Vietnam,T25-W30 AMPTRON,BỘ CHUYỂN DÒNG ĐIỆN T25-W30,BỘ CHUYỂN DÒNG ĐIỆN HOẠT ĐỘNG,Kiểu máy : T25-W10, T25-W12, T25-W13, T25-W20, T25-W30

Amptron Instrumindo

Đại lý AMPTRON Vietnam,BỘ CHUYỂN DÒNG ĐIỆN T25-W30 AMPTRON

Đầu dò đường dây điện chủ động T25-W WATT - T25-W30/AMPTRON

Model : T25-W10, T25-W12, T25-W13, T25-W20, T25-W30
Kích thước : 100 x 78 x 116 mm
I T25-W10 - Đầu dò watt một pha
T25-W12 - Đầu dò watt tải cân bằng 3ph 3W
T25-W13 - Bộ chuyển đổi watt tải cân bằng 3ph 4W
T25-W20 - Bộ chuyển đổi watt tải không cân bằng 3ph 3W
T25-W30 - Bộ chuyển đổi watt tải không cân bằng 3ph 4W
Volatge
69V (3ph 4w ), 120V,240V hoặc
415V, ±25% Tải trọng 0,2VA
Cho phép quá tải 1,25 X liên tục điện áp định mức Quá tải cho phép Liên tục dòng định mức 2 X, dòng định mức 10 X - 10 giây, dòng định mức 25 X - 2 giây, dòng định mức 50 X - 1 giây

Đầu
ra Phạm vi đầu ra
0 ... 1 mA thành 0-1kΩ
0 ... 5 mA thành 0-2kΩ
0 ... 10 mA thành 0-1kΩ
0 ... 20 mA thành 0-500Ω
4 ... 20 mA thành 0-500Ω
0 ... 1 V, tối thiểu 200Ω
0 ... 5 V, tối thiểu 1kΩ
0 ... 10 V, tối thiểu 2kΩ
1... 5 V, tối thiểu 1kΩ
2... 10 V, tối thiểu 2kΩ

phụ trợ

Nguồn cấp Dải tiêu chuẩn 110Vor 220V ±20% 50/60Hz, <3.5VA

Tùy chọn

nguồn riêng và các nguồn điện xoay chiều khác lên đến 440V ac theo yêu cầu.
Các mô hình hỗ trợ DC có sẵn với chi phí bổ sung
