Allen Bradley Vietnam,Bộ điều khiển 1756-L72 Allen Bradley

1756-L72 | Allen Bradley ControlLogix 5570 Controller

Part Number: 1756-L72

Model: ControlLogix 5570 Controller

Brand: Allen Bradley

Condition: New & Original in Factory Packing

Factory Warranty: 12 Months



Model

1756-L72

User memory

4 MB

I/O memory

0.98 MB

Optional nonvolatile memory storage

1 GB (1784-SD1 ships with every controller)
2 GB (1784-SD2)

Digital I/O, max

128,000

Analog I/O, max

4000

Total I/O, max

128,000

Energy storage module

1756-ESMCAP capacitor energy storage module (removable, ships installed with every controller)
1756-ESMNSE capacitor energy storage module (removable, no residual WallClockTime power backup)
1756-ESMNRM capacitor energy storage module (nonremovable, secures controller by preventing USB connection an d SD card use)

Current draw @ 1.2V DC

5 mA

Current draw @ 5.1V DC

800 mA

Power dissipation

2.5 W

Thermal dissipation

8.5 BTU/hr

Isolation voltage

30V (continuous), basic insulation type, USB port-to-system
Type tested at 500V AC for 60 s

USB port¹

USB 2.0, full speed (12 Mbps)

Weight, approx

0.25 kg (0.55 lb)

Slot width

1

Module location

Chassis-based, any slot

Wire category²

3 - on USB port

North American temperature code

T4A

IEC temperature code

T4

Enclosure type rating

None (open-style)



  1. The USB port is intended for temporary local programming purposes only and not intended for permanent connection. Do not use the USB port in hazardous locations.

  2. Use this conductor category information for planning conductor routing as described in the system level installation manual.
