SPECIFICATION
|
EP-30100
|
EP-6050
|
EP-15020
|
|||
|
POWER
|
3kW
|
3kW
|
3kW
|
|||
|
VOLTAGE
|
0 ~ 30V
|
0 ~ 60V
|
0 ~ 150V
|
|||
|
CURRENT
|
0 ~ 100A
|
0 ~ 50A
|
0 ~ 20A
|
|||
|
RIPPLE REJECTION (rms/p-p)
|
1㎷/10㎷
|
2㎷/20㎷
|
5㎷/50㎷
|
|||
|
LOAD REGULATION
|
6㎷
|
12㎷
|
30㎷
|
|||
|
LINE REGULATION
|
20 ㎷
|
20 ㎷
|
20 ㎷
|
|||
|
VOLTAGE RESOLUTION
|
0.01V → 0.1V
|
0.01V → 0.1V
|
0.01V → 0.1V
|
|||
|
CURRENT RESOLUTION
|
0.01A → 0.1A
|
0.01A → 0.1A
|
0.001A -> 0.01A
|
|||
|
TRANSIENT RECOVERY TIME
|
100㎲(50% Load Current Change Minimum Load 0.5A)
|
|||||
|
DISPLAY
|
VOLTAGE
|
3 ½ Auto Range Digital Display
|
||||
|
CURRENT
|
3 ½ Auto Range Digital Display
|
|||||
|
PROTECTION
|
OVER VOLTAGE
|
Full Scale of DC Output Voltage + 3%
|
||||
|
OVER CURRENT
|
Full Scale of DC Output Current + 3%
|
|||||
|
TEMPERATURE
|
Heat Sink 85℃
|
|||||
|
OPERATING ENVIRONMENT
|
0~50 ℃, 80%R.H.
|
|||||
|
AC POWER SOURCE
|
AC 220V ± 10% , 60 ㎐
|
|||||
|
ANALOG INPUT FOR VOLTAGE CONTROL
|
0~Full Scale of DC Output Voltage / 0~10V
|
|||||
|
V-SENSE
|
Compensation of Voltage Drop
|
|||||
|
ACCESSORIES
|
Input Power Cord, Manual, Output Cable
|
|||||
|
Weight(Approx)
|
120 kg
|
120 kg
|
120 kg
|
|||
|
DIMENSION(W*H*D ㎜)
|
420 x 720 x 680
|
420 x 720 x 680
|
420 x 720 x 680
|
|||
