• According to
- Performance Level (PL) e and category 4 to EN ISO 13849-1: 2008
- SIL Claimed Level (SIL CL) 3 to IEC/EN 62061
- Safety Integrity Level (SIL 3) to IEC/EN 61508
• Safety outputs can be assigned to one or several function modules
(control unit or input modules).
• Outputs:
- 4 NO contacts
- 3 NO contacts, 1 NC contact
- 3 NO contacts 0-3 s delay-release time-delay relay
- 2 NO contacts, 1 NC contact 0-3 s delay-release time-delay relay
• Permanently monitored feedback loop for external contact reinforcement
• LEDs for status indication
• Width 22.5 mm
