Model: PRK18B.T2/PX-M12 Cảm biến quang Photoelectric sensor Leuze

Specifications:

    Series 18B

    Operating principle Reflection principle

    Application Detection of highly transparent bottles, Detection of highly transparent films and glass panes

    Operating range 0 ... 4 m

    Operating range limit 0 ... 4.8 m

    Light source LED, Red

    Supply voltage UB 10 ... 30 V, DC

    Residual ripple 0 ... 15 %, From UB

    Open-circuit current 0 ... 18 mA

    Switching element Transistor, PNP

    Switching principle Dark switching

    Switching frequency 1,500 Hz

    Response time 0.333 ms

    Function Voltage supply, Signal OUT

    Type of connection Connector

    Thread size M12

     Materia Metal

No. of pins 4 -pin
