Origin

Hãng sản xuất

Model và mô tả

100% USA Origin

Watlow Vietnam

Code: 2223-3704
25" DIAMETER FIREROD
Diameter [in] (B) .246" +/- .002"
 Overall Length [in] (A) 4.400
Length Tolerance +/- 3/32
Voltage [V] 240
Power [W] 300
Wattage Tolerance [%] + 5%,- 10%
Terminations Right Angle Leads
End Seal No Seal
Lead Type High Temp (MGT)
Lead Length [in] (E) 12
Sheath Materials Incoloy 800
LINE 4 2223-3704
CE No
Lead End No Heat [in] 'NOM' (D) 0.476
Disk End No Heat [in] 'NOM' (C) 0.250
Watt Density [w/in2] nom 103

100% USA Origin

Watlow Vietnam

Code:  2221-5688
25" DIAMETER FIREROD
Diameter [in] (B) .246" +/- .002"
 Overall Length [in] (A) 4.000
Length Tolerance +/- 3/32
Voltage [V] 240
Power [W] 300
Wattage Tolerance [%] + 5%,- 10%
Terminations Right Angle Leads
End Seal No Seal
Lead Type High Temp (MGT)
Lead Length [in] (E) 12
Sheath Materials Incoloy 800
LINE 4 2221-5688
CE No
Lead End No Heat [in] 'NOM' (D) 0.476
Disk End No Heat [in] 'NOM' (C) 0.250
Watt Density [w/in2] nom 115
