Cảm biến áp suất_P-502C Series

Material (wetted parts)

stainless steel 316L or comparable

Process connections

compression type or face seal couplings

Seals

standard: Viton^®; options: EPDM, Kalrez^® (FFKM)

Weight

0,4 kg

Ingress protection (housing)

IP40

Power supply

+15…24 Vdc

Max. power consumption
meter

Supply
15 V
24 V

at voltage I/O
67 mA
49 mA

at current I/O
90 mA
67 mA

Max. power consumption
controller

Supply
15 V
24 V

at voltage I/O
223 mA
150 mA

at current I/O
223 mA
150 mA

PROFIBUS DP

add 53 mA (15 V supply) or 30 mA (24 V supply)

PROFINET

add 77 mA (15 V supply) or 48 mA (24 V supply)

EtherCAT^®

add 66 mA (15 V supply) or 41 mA (24 V supply)

DeviceNet™

add 48 mA (24 V supply)

Analog output/command

0...5 (10) Vdc or 0 (4)…20 mA (sourcing output)

Digital communication

standard: RS232;
options: PROFIBUS DP, DeviceNet™, PROFINET, EtherCAT^®, Modbus RTU or ASCII, FLOW-BUS
