Lưu lượng kế_MODEL 2503F

Xuất sứ: JAPAN

Nhà cung cấp: ANS- ANH NGHI SƠN ĐÀ NẴNG

Hãng sản xuất: KOFLOC VIET NAM

Ứng dụng sản phẩm: Automotive

Liên hệ tư vấn

Ms. Diệu

dieu.ans@ansvietnam.com

0902337066

0962678764

anhnghisonhcm

* Đặt điểm

• This flow meter ensures constant flow under constant pressure on its inlet side even if the load pressure loss on the outlet side changes.
• The measuring section of the flow meter is based on the highprecision float type flow meter RK1400.
• The precision valve permits smooth and stable control of very small flow.
• Constant pressure on the inlet side eliminates pressure errors of the float type flow meter, allowing a complete flow control system to be configured.

* Thông số

Fluids Air,N2,O2,H2,He,Ar,CO2 (Calibration with actual gas)
For other gases, please consult us regarding conversion conditions
or calibration with the actual gas to be used.
* Option: Scales for two types of fluids
Flow range (FS) From 1–10 ML/MIN to 2–20 L/MIN (Refer to the Capacity Table on page 55.)
Accuracy FS ±2% (Measurement point) (under specified constant primary pressure)
Control pressure The pressure difference between inlet and outlet must be 0.05 MPa or more.
Proof pressure 5 L/MIN or less: 0.8 MPa
10 L/MIN or more: 0.5 Mpa
Available scale 10:1


Material SS Al
Body block SUS316 Al, Brass
Tapered tube Pyrex®, glass
Packing FKM NBR
Float Pyrex, SUS316, glass
Protective cover Acrylic resin
Heat resistance MAX60℃
Connection Rc 1/4 (Standard), Rc 1/8 (Optional)
