■For high temperature scrap handling (up to 600℃)

Type LMCH-
70HAS
LMCH-
90HAS
LMCH-
110HAS
LMCH-
130HAS
LMCH-
150HAS
LMCH-
180HAS
LMCH-
210HAS
Dimensions A mm 700 900 1100 1300 1500 1800 2100
B (approx.) 785 1150 1160 1340 1360 1560 1960
C (approx.) 140 175 175 220 220 310 350
D 90 125 125 175 175 210 250
E 29 38 38 50 50 60 80
Weight (approx.) kg 550 1000 1650 2300 3200 5000 7500
Current (before running) A 14 21 29 50 61 77 110
Cold power consumption kW 3.0 4.6 6.3 11.1 13.4 17 24.2
Lifting capacity
(before running)
Impact ball kg 2500 4500 6500 8500 11000 14500 21000
Pig iron 380/200 600/400 1100/800 1400/1100 1900/1500 2750/2100 3500/2800
Crop-end 380/200 600/400 1100/800 1400/1100 1900/1500 2750/2100 3500/2800
No.1 heavy melting scrap 120/100 250/200 450/400 700/600 1100/900 1600/1350 2200/1850
No.2 heavy melting scrap - - 150/100 250/200 400/300 600/450 900/700
Cast iron chips 120/100 250/200 450/400 700/600 1100/900 1600/1350 2200/1850

Capacities are based on tests under optimum conditions. Performance will vary with specific operations.

No.1 H.M.S: Grinding dust of thick blooms (Thickness:over 6mm, width:less than 600mm, length:less than 1500mm)
No.2 H.M.S: Dust(thickness:over 3mm, wideth: less than 450mm, length: less than 900mm)include steel plate, shaped steel and car scrap.

Note)
  1. Ability might differ when you use LMP-192-D in area of 50Hz, hanging voltage will be DC270V.
  2. Hanging capacity increase 10% when starting up over shoot DC350V or 490V, and hanging over excitation DC290V (DC200V while lifting).
  3. Measurement C of LMCK-175~245HA-6 is included measurement of protector.
  4. Type of cab tire cable is 2PNCT (5.5mm2), and PNCT for lifting magnet (14~38mm2).
  5. Hanging capacity might change depend on shape, dimensions, and state of compile of handling scrap. Therefore, hanging capacity is not reference.
Outline Dimensions

  •
