LMCK-HA-6 Industrial Electrical Equipment  & Power System Sinfonia Vietnam ANSdanang

■For normal temperature scrap handling (up to 100℃)

Type LMCK-
52HA-
6		 LMCK-
72HA-
6		 LMCK-
82HA-
6		 LMCK-
92HA-
6		 LMCK-
115HA-
6		 LMCK-
135HA-
6		 LMCK-
155HA-
6		 LMCK-
175HA-
6		 LMCK-
185HA-
6		 LMCK-
215HA-
6		 LMCK-
245HA-
6		 Rated
voltage
Outline Dimention Figure A Figure B
Dimensions A mm 550 750 850 950 1150 1350 1550 1750 1850 2150 2450
B 520 720 820 920 1150 1350 1550 1750 1850 2150 2450
C 416 413 403 365 386 414 425 462 484 512 542
D 796 824 814 794 1020 1190 1260 1400 1420 1760 2060
E 19 28 28 28 38 50 50 60 60 80 90
F 120 160 160 160 200 250 250 350 350 400 450
G 65 90 90 90 125 175 175 210 210 250 280
Weight (approx.)
With hanging chain		 kg 290 570 625 795 1340 2090 2800 3850 4500 6800 9650
Hanging capacity
and voltage
(When cold
or hot)

Constant
voltage system		 Current
(when cold)		 A 10.9 15.5 21.4 23.2 31.8 56.4 65 70 78.6 112.7 153.2 DC220V
Power
consumption
(when cold)		 kW 2.4 3.4 4.7 5.1 7 12.4 14.3 15.4 17.3 24.8 33.7
Falling ball kg 1500 2500 3500 4500 6500 8500 11000 13000 14500 20000 23000
Pig iron 210
/180		 400
/340		 520
/440		 660
/560		 1030
/870		 1640
/1430		 2160
/1880		 2750
/2400		 3080
/2680		 4160
/3620		 5400
/4700
Crop end 210
/180		 400
/340		 520
/440		 660
/560		 1030
/870		 1640
/1430		 2160
/1880		 2750
/2400		 3080
/2680		 4160
/3620		 5400
/4700
No. 1 H.M.S. 100
/70		 200
/150		 250
/200		 320
/250		 545
/460		 870
/735		 1220
/1055		 1590
/1360		 2140
/1740		 2890
/2350		 3745
/3045
No. 2 H.M.S. - - - 100
/60		 200
/100		 300
/200		 450
/300		 600
/400		 650
/450		 1000
/700		 1500
/1000
Cast iron
grinding dust		 65
/55		 200
/150		 250
/200		 320
/250		 545
/460		 870
/735		 1220
/1055		 1590
/1360		 2140
/1740		 2890
/2350		 3745
/3045
Components Cable connector H-230E H5-260E PJW-102 PJW-202 AC200
/220V
When
receiving
power
Cable drum
(For 15m)		 CSN-11WR U5-C1502G1 U5-
E1502G2		 U5-
E1502G3
Attached
cabtire cable		 5.5mm2, 2 hearts
13m×1		 14mm2, 2 hearts
20m×1		 22mm2,
2 hearts
20m×1		 38mm2,
2 hearts
20m×1
Power panel LMP-72A-D LMP- 192A-D LMP- 194A-D LMP- 254A-D LMP- 454A-D
Power
receiving box		 NFI-05SW NFI-1SW NFI-2SW NFI-4SW
Inverter 10kVA 19kVA 45kVA 60kVA 105kVA
Instrument
casing		 MPB-211-5C MPB-
211-
15C		 MPBS- 2111-15D MPBS- 2111-
20G		 MPBS- 2111-
35G
When using
controller		 MCS-2
When using
two-points
push button		 KGN2112NY
When using
eight-points
push button		 COB-74

Crop end: Grinding dust of ingot, billet blooms

No.1 H.M.S: Grinding dust of thick blooms (Thickness:over 6mm, width:less than 600mm, length:less than 1500mm)
No.2 H.M.S: Dust（thickness:over 3mm, wideth: less than 450mm, length: less than 900mm）include steel plate, shaped steel and car scrap.

Note)
  1. Ability might differ when you use LMP-192-D in area of 50Hz, hanging voltage will be DC270V.
  2. Hanging capacity increase 10% when starting up over shoot DC350V or 490V, and hanging over excitation DC290V (DC200V while lifting).
  3. Measurement C of LMCK-175～245HA-6 is included measurement of protector.
  4. Type of cab tire cable is 2PNCT (5.5mm2), and PNCT for lifting magnet (14～38mm2).
  5. Hanging capacity might change depend on shape, dimensions, and state of compile of handling scrap. Therefore, hanging capacity is not reference.
Outline Dimensions

  •
