Model: ZPBD 2-23,60-KIK-L-FCB/R/MAG(20-G)/V1 ǀ Máy bơm Beinlich-pumps

Model: ZPBD 2-23,60-KIK-L-FCB/R/MAG(20-G)/V1  ǀ  Máy bơm Beinlich-pumps

Thông số kỹ thuật:

Number of Stages        : 1

Theo. Volume               : 23,60  cm³/rev

Inlet Pressure   max.     : 0-20    bar

Work Pressure  max.     : 40       bar

Peak Pressure  max.     : 60       bar       (Short operation)

Speed              max.*   : 1450   min^-1

Suction Port                 : G1 1/4

Pressure Port               : G1

Sense of Rotation         : LEFT (ccw), in view of drive shaft

Design                         : External Spur Gear, bare shaft

Sealing Type                : Canister of Magnetic Coupling DST75

Version                        : With attached Pressure Valve

Ambient Temperature    : -30°C min./ +60°C max.

Materials

Housing                       : Spheroidal Cast Iron 1

Center Plate                 : Spheroidal Cast Iron 1

Gears                           : Nitrided Steel

Drive Shaft                   : Nitrided Steel

Driven Shaft                 : Nitrided Steel

Bearing Bushes            : Ceramic

Seals                           : FKM

Pressure Relief Valve

Operation                     : Direct

Spring                          : Pressurespring

Setting range                : 0 - 120 bar

Pressure adjustment at : (see Application Data)

Return flow                  : Externally

Seals                           : FKM

Material                                    : Steel
