Description

Active Front End Regenerative Power Supply Unit, from 22kW to 1.65MW

400V series:
* Power supply: 380VAC -15% …500VAC +5%, 50/60Hz
* Power ratings: from 22kW to 1.2MW

690V series:
* Power supply: 500VAC -10% …690VAC +10%, 50/60Hz
* Power ratings: from 160kW to 1.65MW

* Cosphi  0,99
* Overload 150% for 60 sec every 5 minutes (Heavy duty) or 110% for 60 sec every 5 minutes (Light duty)
* IP20-rated protection (IP00 size 7 and parallel)
* Certifications: CE. UL, cUL

Features:
- Integration of up to 2 options on board the drive
- GF-eXpress multi-language programming SW (5 languages)
- Integrated KB_ADV programming keypad

Inputs / Outputs:

  • 2 bipolar analog inputs (Voltage/Current)
  • 2 bipolar analog outputs (1: Voltage/Current, 1: Voltage)
  • 6 digital inputs (PNP/NPN)
  • 2 digital outputs (PNP/NPN)
  • 2 relay outputs, single contact
  • RS485 serial line (Modbus RTU)

Fieldbus management:

  • DeviceNet, Modbus, GDnet, CANopen, Ethercat, PROFIBUS, PROFINET

Conformity:

  • Climatic conditions: EN 60721-3-3
  • Electrical safety: EN 50178, EN 61800-5-1, UL508C, UL840 pollution level 2
  • Vibrations: EN 60068-2-6, test Fc.
  • EMC EN61800-3

Environmental conditions:

  • Ambient temperature: 0 ...40°C, +40°C…+50°C with derating
  • Altitude: Max 2000 m.

Markings:

  • CE: Complies with the EEC directive concerning low voltage equipment.
  • UL-cUL:  Complies with directives for the American and Canadian market
