Side-by-side, flexible, and energy-efficient servo converter

Baumüller sets standards with the converter generation b maXX 5000. The further development of the successful b maXX series towards modular systems convinces with high-performance power units in air-cooled, water-cooled and cold plate cooling versions and with flexible expandability and the accessibility to an integrated communication concept. Standardized as well as complex automation solutions can be implemented with Baumüller’s converters and controllers within a power range between 1 and 90 kW.

The machine and installation requirements with regard to future reliability, flexible expansion possibilities and a simple adjustment to changed production processes were already considered during the preliminary development process stages of the b maXX 5000.


Ordering code Frame size IN [A] IMAX[A] typ. motor power [kW] Overload factor Dimensions WxHxD [mm]

BM 5323 2 2 x 3 2 x 9 2 x 1.6 3 50 x 395 x 280 / 210 1)
BM 5325 2 2 x 6 2 x 18 2 x 3.2 3 50 x 395 x 280 / 210 1)
BM 5326 2 12 24 6.5 2 50 x 395 x 280 / 210 1)
BM 5327 2 20 40 10.8 2 50 x 395 x 280 / 210 1)
BM 5328 2 30 60 16.2 2 50 x 395 x 280 / 210 1)
BM 5331 3 2 x 12 2 x 24 2 x 6.5 2 75 x 395 x 280 / 210 1)
BM 5332 3 2 x 20 2 x 40 2 x 10.8 2 75 x 395 x 280 / 210 1)
BM 5333 3 2 x 30 2 x 60 2 x 16.2 2 75 x 395 x 280 / 210 1)
BM 5334 3 40 60 21.6 1.5 75 x 395 x 280 / 210 1)
BM 5335 3 60 90 32.4 1.5 75 x 395 x 280 / 210 1)
BM 5372* 7 90 180 48.6 2 175 x 395 x 250 2)
BM 5373* 7 120 240 64.8 2 175 x 395 x 250 2)
BM 5374* 7 150 300 81 2 175 x 395 x 250 2)
BM 5375* 7 180 360 97.2 2 175 x 395 x 250 2)
BM 5382* 8 210 360 113.4 1.7 225 x 395 x 250 2)
BM 5383* 8 250 375 135 1.5 225 x 395 x 250 2)
