100% UK Origin

Katronic Technologies Vietnam

Model: KF150-2-03-1-1-0CDRB-1-0-0-0-000/SU
KF150 Ultrasonic flow meter KATflow 150, serial interface RS 232, operating instructions
-2 2 measurement channels
-03 Version code: 03
-1 Power supply: 100 … 240 V AC, 50/60 Hz
-1 Enclosure type: Polycarbonate (UL94 V-0), wall mount, IP 66
-0 Communication: Without
-CDRB Process inputs/outputs:
Slot 1: Current output 0/4 … 20 mA, active (source),
Slot 2: Digital output, Open-Collector,
Slot 3: Digital output, relay,
Slot 4: Current input board, 4 … 20 mA passive (sink),
-1 Internal data logger: 30,000 measurements
-0 Temperature compensation (TC) / Heat quantity measurement (HQM): Without
-0 Sound velocity output (SVO): Without
-0 PT100 extension cable: Without
000 PT100 extension cable length in m: Without
/SU Optional items: KATdata+ download software, USB cable

100% UK Origin

Katronic Technologies Vietnam

Model: K1N-1-1-50-J-C005
K1N Transducer pair, pipe diameter range 50 … 3000 mm,
Process temperature -30 ... 130 ºC, cable length 3.5 m, including KEEprom and acoustic coupling paste, with direct SMB connectors
-1 Version number: 1
-1 Degree of protection: IP 66 (standard)
-50 Transducer mounting accessories: Metallic straps and clamps DN 25 … 3000, Stainless steel tag: Without
-J Transducer connection: With standard junction box
-C005 Extension cable length: 005 m

100% UK Origin

Katronic Technologies Vietnam

Model: KF200-1-03-1-1-1-0
KF200 Hand-held KATflow 200, one measurement channel, serial interface RS 232
-1 With crush-proof transport case IP 67, power adapter/battery charging unit, operating instructions, measuring tape
-03 Internal code: 03
-1 Power adapter: UK
-1 Degree of protection: IP 65 (standard)
-1 Internal data logger: 30,000 measurements, KATdata+ download software, RS 232 cable
-0 Wall thickness measurement: Without/ Optional items: Without

100% UK Origin

Katronic Technologies Vietnam

Model: K1N-1-1-50-P-E005
K1N Transducer pair, pipe diameter range 50 ... 3000 mm,
Process temperature -30 ... 130 °C, including acoustic coupling paste, standard cable length
-1 Internal code: 1
-1 Degree of protection: IP 66 (standard)
-50 Transducer mounting accessories: Clips and chains DN 25 ... 600
-P ODU/LEMO transducer plug
-E005 Transducer extension cable: With extension cable, 5 m length
/ Optional items: Without
