2930B SERVOTOUGH LaserSP




02930B1

SERVOTOUGH LaserSP

CONFIGURATION




Single Path

AREA CLASSIFICATION




Safe Area


ATEX  and IECEx Cat 3 Gas (Zone 2) Cat 2 Dust (Zone 21)


ATEX Cat. 2G (Zone 1)


CSA general purpose


CSA Class 1, Division 2


MEASUREMENT



Single Path monitors

Measurement



O2 SERVOTOUGH LaserSP Monitor (oxygen)


HOT O2 SERVOTOUGH LaserSP Monitor (oxygen)


CO SERVOTOUGH LaserSP Monitor, low level detection limit 0.3ppm (carbon monoxide)


NH3 SERVOTOUGH LaserSP Monitor (ammonia)


MEASURING RANGE




Please state

MEASUREMENT UNITS




mg/m3


ppm


% vol


DUAL MEASUREMENT




Not Required


Dual gas, add on temperature (for O2 and CO)


DUAL MEASURING RANGE




Please state


DUAL MEASUREMENT UNITS




mg/m3


ppm


% vol


Celsius



Gas Component 1


Stream Comp 1 Normal Range


Stream Comp 1 Low Range


Stream Comp 1 High Range


Process Dust (mg/m3)


Process Flow (m3/h)


Process Velocity (m/sec)


Process Opacity (%)


Stream Temperature (°C)


Ambient Temperature (°C)



Trans/Rec Cable 10m (5m supplied as standard)


Trans/Rec Cable 15m (5m supplied as standard)


Trans/Rec Cable 20m (5m supplied as standard)


TU/RU Connecting Cable 5-20m (per metre). 5m supplied as standard.



TU Optical Path Length L1 (mm)


Stack Diameter L2 (mm)


RU Optical Path Length L3 (mm)
