Đặt điểm

Input: overpressure (0,1 bar up to 1000 bar) / absolute pressure (0,25 bar up to 25 bar)

Output: 4...20 mA current loop (15...45 VDC), HART-protocol

Option: additionally with limit value contacts

Turn down: up to 100:1

Accuracy: <0,25% of sensor range (up to 0,25 bar: <0,5% of sensor range)

Indication: LCD-display with backlighting

Configuration: with keys and/or software

Enclosure for electronics: diecast aluminium (degree of protection: IP65 )

Process connection: G1/2B / G1/4B / G1/4A / 1/2NPT / 1/4NPT / M20x1,5 (pressurized parts: NiCr steel)
