SPECIFICATION
|
MODEL
|
EDP-3030
|
EDP-3003
|
EDP-5020
|
||
|
OUTPUT
|
Watt
|
900W
|
900W
|
1000W
|
||
|
Voltage
|
0 ~ 30V
|
0 ~ 300V
|
0 ~ 50V
|
|||
|
Current
|
0 ~ 30A
|
0 ~ 3A
|
0 ~ 20A
|
|||
|
Programming Accuracy
(At 25℃±5℃) |
Voltage
|
0.1% + 10㎷
|
0.1% + 100㎷
|
0.1% + 17㎷
|
||
|
Current
|
0.1% + 30㎃
|
0.1% + 3㎃
|
0.1% + 50㎃
|
|||
|
RIPPLE & NOISE
(from 20Hz to 20MHz) |
Voltage(rms/p-p)
|
1㎷/10㎷
|
9㎷/90㎷
|
2㎷/20㎷
|
||
|
Current
|
60㎃
|
6㎃
|
40㎃
|
|||
|
Read back Accuracy
(At 25℃±5℃) |
Voltage
|
0.1% + 10㎷
|
0.1% + 100㎷
|
0.1% + 17㎷
|
||
|
Current
|
0.1% + 30㎃
|
0.1% + 3㎃
|
0.1% + 20㎃
|
|||
|
LOAD REGULATION
|
Voltage
|
6㎷
|
60㎷
|
10㎷
|
||
|
Current
|
30㎃
|
3㎃
|
20㎃
|
|||
|
LINE REGULATION
|
Voltage
|
20㎷
|
20㎷
|
20㎷
|
||
|
Current
|
100㎃
|
100㎃
|
100㎃
|
|||
|
CONTROL
RESOLUTION |
Voltage
|
10㎷
|
100㎷
|
10㎷
|
||
|
Current
|
10㎃
|
1㎃
|
1㎃
|
|||
|
DISPLAY
(16×2 LCD ) |
Voltage
|
4 ½ Auto Range of 5 Reading/s
|
||||
|
Current
|
4 ½ Auto Range of 5 Reading/s
|
|||||
|
PROTECTION
SETTING |
Over Voltage
|
Full Scale of DC Output Voltage + 3%
|
||||
|
Over Current
|
Full Scale of DC Output Current + 3%(Only OCP Set Mode)
|
|||||
|
Temperature
|
Heat Sink 85℃
|
|||||
|
AUTO SEQUENCE
(DYNAMIC) |
Auto Run Step
|
Maximum 100 Step
|
||||
|
Setting Time
|
1ms ~ 50,000s
|
|||||
|
Slope Time
|
1ms ~ 50s
|
|||||
|
Repeat Cycle
|
1 ~ 50,000 Cycle ("0" Set: ∞)
|
|||||
|
TRANSIENT RECOVERY TIME
|
100㎲(50% Load Current Change Minimum Load 0.5A)
|
|||||
|
OPERATING ENVIRONMENT
|
0~50 ℃, 80%R.H.
|
|||||
|
MEMORY ADDRESS
|
Max. 100 Points (Voltage, Current, Time, Slope)
|
|||||
|
INTERFACE FOR PC
|
Built-in RS-232C(RS-485), GP-IB(Option)
|
|||||
|
AC POWER SOURCE
|
AC 220V ± 10% , 60㎐
|
|||||
|
WEIGHT (APPROX)
|
57 kg
|
52 kg
|
55 kg
|
|||
|
DIMENSION(W x H x D ㎜)
|
420 x 200 x 500
|
420 x 200 x 500
|
420 x 200 x 500
|
|||
