Mô tả:

  • Strokes from 50 to 1000 mm

  • Magnetic pulling of cursor

  • Mechanical anchoring and self-aligning pulling on 2 ball joints

  • Max. angle of movement up to ± 26°

  • Independent linearity up to fino a ± 0.05%

  • Repeatability: 0.08 mm

  • Hysteresis: 0.25 mm

  • Infinite resolution

  • No electrical variation of electrical output signal outside theoretical electrical stroke

  • Work temperature: -30°...+100°C

  • Electrical connections: cable output shielded with highly flexible polyurethane, 3-pin, 1 m

  • Life: > 25x106 m strokes, or >100x106 maneuvers, whichever is less (within U.E.S.)

  • Protection level: IP67 (CEI EN 60529)
