Model: PRK46C.1/4P-M12 Cảm biến quang Photoelectric sensor Leuze

Features:

Series: 46C

Operating principle: Reflection principle

Operating range: 0.1 ... 24 m, With reflector TK(S) 100x100

Operating range limit: 0.1 ... 30 m, With reflector TK(S) 100x100

Light source: LED, Red

Protective circuit: Polarity reversal protection, Short circuit protected, Transient protection

Supply voltage UB: 10 ... 30 V, DC, Incl. residual ripple

Residual ripple: 0 ... 15 %, From UB

Open-circuit current: 0 ... 20 mA

Switching frequency: 500 Hz

Response time: 1 ms

Function: Voltage supply, Signal OUT

Type of connection: Connector

Thread size: M12

Material: Plastic

No. of pins: 4 -pin
