Mr. HuyOverall Accuracy
| Model | ACSⅡ-1000 | ACSⅡ-2000 | ACSⅡ-3000 | ACSⅡ-4000 | ||
| Calibration Object | Surface | Internal | Surface | Internal | ||
| Range | Rt to 100°C | +0.5 / -0.7°C | +0.5 / -0.7°C | ±0.26°C | +0.4 / -0.6°C | ±0.26°C |
| 100 to 200°C | +0.5 / -1.1°C | +0.5 / -1.1°C | ±0.32°C | +0.3 / -0.9°C | ±0.32°C | |
| 200 to 300°C | +0.5 / -1.5°C | +0.5 / -1.5°C | ±0.37°C | +0.1 / -1.1°C | ±0.37°C | |
| 300 to 400°C | — | +0.4 / -2.0°C | ±0.43°C | +0.2 / -1.5°C | ±0.43°C | |
| 400 to 500°C | — | -0.1 / -2.9°C | ±0.48°C | -0.9 / -2.2°C | ±0.48°C | |
Control Unit
| Model | ACSⅡ-1000 | ACSⅡ-2000 | ACSⅡ-3000 | ACSⅡ-4000 | |
| Surface Range | Rt to 300°C | Rt to 500°C | — | Rt to 500°C | |
| Internal Range | — | — | Rt to 500°C | Rt to 500°C | |
| Control Principle | PID auto-Tuning Control | ||||
| Control | Input | Pt 100Ω, ø3.2 | |||
| Accuracy | ±(0.2% of reading)°C | ||||
| Display | 8mm high LED display | ||||
| Reference Sensor |
Input | — | Pt 100Ω, ø4.8 | ||
| Accuracy | — | ±(0.05% of reading +0.05)°C | |||
| Display | — | 12.5mm high LED display | |||
| Power Consumption | App.160W | App.700W | App.1600W | ||
| Dimensions (mm) | 320(W)×177(H)×350(D) | 430(W)×177(H)×350(D) | |||
| Weight | App.4.5kg | App.5.0kg | |||
