  • Measures real-time and peak force values
  • Ergonomic lever operation produces 200 lbF [1,000 N]
  • USB, RS-232, Mitutoyo (Digimatic), and analog outputs
  • Automatic output / data storage / zeroing upon sample break helps automate testing processes
  • 1,000-point data memory with statistics and outputs
  • Password protection prevents unauthorized changes
  • Programmable set point indicators and outputs for pass/ fail determination
  • High-speed 7,000 Hz sampling rate accurately captures peak force values
  • Configurable audio alarms and key tones
  • Mounting holes for bench mounting
  • CE mark



Capacity x Resolution:  200 x 0.1 lbF, 3200 x 2 ozF, 100 x 0.05 kgF, 1000 x 0.5 N, 1 x 0.0005 kN
Accuracy:    ±0.2% of full scale
Wire gauge range*:   AWG30 - AWG3*
Wire diameter range:   0.01 - 0.25 in [0.3 - 6.3 mm]
Minimum sample length:   6.5 in [165 mm], excluding termination
Maximum sample elongation:   1.15 in [29.2 mm]
Power:   AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low.
Battery Life:   Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use
Sampling rate:   7,000 Hz
Outputs:   USB / RS-232: Configurable up to 115,200 baud. .
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible Devices.
Analog: ±1 VDC, ±0.25% of full scale at capacity.
Set points: Three open drain lines.
Safe overload:   150% of full scale (display shows "OVER" at 110% and above)
Weight:   16.1 lb [7.3 kg]
Included items:   Universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESUR™Lite software, MESUR™gauge and MESUR™gauge Plus 90-day trial, and user's guide), NIST-traceable certificate of calibration
Warranty:   3 years (see individual statement for further details)
