200 x 0.1 lbF | 3200 x 2 ozF | 100 x 0.05 kgF | 1,000 x 0.5 N | 1 x 0.0005 kN |
| Accuracy: |
±0.2% of full scale |
| Wire gauge range: | AWG30 - AWG 3 [0.01 - 0.25 in (0.3 - 6.3 mm) dia.] |
| Sample length range: | Minimum 6.5 in [165 mm], excluding termination |
| Max. elongation: | 1.7 in [43 mm] |
| Speed range: | Test speed: 0.4 - 12.0 in/min [10 - 300 mm/min] Approach/reverse speed: 13.0 - 96.0 in/min [325 - 2,400 mm/min] |
| Speed setting accuracy: | ±0.2% |
| Speed variation with load: | ±0% [Stepper motor driven] |
| Power: | Universal input 80-240 VAC, 50/60 Hz |
| Sampling rate: | 7,000 Hz |
| Outputs: | USB / RS-232: Configurable up to 115,200 baud. Mitutoyo: Serial BCD suitable for all Mitutoyo SPC-compatible devices. Analog: ±1 VDC at capacity, ±0.25% of full scale. General purpose: Three open drain outputs, one input. Set points: Three open drain lines. |
| Safe overload: | 150% of full scale (display shows "OVER" at 110% and above) |
| Weight: | 26.5 lb [12.0 kg] |
| Included items: | Power cord, quick-start guide, USB cable, resource CD (USB driver, MESUR™ Lite software, MESUR™gauge and MESUR™gauge Plus 90-day trial, and user's guide), and NIST-traceable certificate of calibration. |
| Environmental requirements: | 40 - 100°F, max. 96% humidity, non-condensating |
| Warranty: | 3 years (see individual statement for further details) |
