ADP200 inverter for servopump applications VIET NAM

Full vector Inverter from 7.5 kW up to 75 kW with special PID function for servopump hybrid injection machines

* Mains supply:
- 3 x 230-400 -480 VAC, 50/60Hz
* Motor ratings from 7,5kW (10Hp) to 75kW (100Hp)

* Certifications: CE, cULus

Features:

• Motor type: Synchronous Motors
• Regulation control mode: Vector control with feedback (Encoder expansion card mandatory)
• Max Output frequency 300Hz
• DC side choke integrated in ADP200-4300...5750 models.
• AC side external choke mandatory in ADP200-5S550 and ADP200-5S750 models
• EMC Filter Integrated in -F models (EN61800-3 category C2 and C3)
• Dynamic Braking Module Integrated with external resistor (except ADP200-5750 model)
• Overload management 170% x In (per 60 sec.), 200% x In (per 3 sec)
• Multilanguage programming software
• Advanced programming via MDPLC tool (IEC 61131-3 standard environment)
• Integrated simplified programming keypad and optional keypad with multiple languages LCD display
• 3 differential analog inputs:
  1 for pressure sensor:
  Voltage: 0…10 V or 0.1…10.1 V (3 wires)
  Current: 0…20 mA or 4…20mA (2 wires)

          2 for flow/pressure references or general purpose:
          Voltage: +/- 10 V
          Current: 0…20 mA or 4…20 mA

• 1 Analog output: 0…10 V o 0~20mA /4~20mA
• 6 Digital Inputs + enable
• 2 Digital Outputs
• 2 Relay Outputs
• 1 motor protection input (compatible with PTC, KTY, Klixon)
• RS485 Serial Line (Modbus RTU protocol)
• Integrated CAN fieldbus communication (in –C version)
• Speed feedback through Resolver card
• Wide range of optional encoder cards
• Integrated Slot for SD card
• IP20 protection degree

*Above listed features represent standard configuration with EXP-IO-D8A4R2-ADP (I/O card) and EXP-RES-I1-ADP (resolver card)
