■Outer Dimensions:FV Series Flow Control Values

■Dimensions

Unit:mm

Model A B C D E F G H I J K L Weight(kg)
Type A Type S
 FV-4A(S) 100 155 140 162 32 60 M6-3 φ7-3 60゚ 11 10 11 1.2 2.2
 FV-6A(S) 150 230 214 214.5 35 90 M8-3 φ9-3 60゚ 11 12 12 2.5 4.4
 FV-8A(S) 204 283 267 241 35 115 M8-3 φ9-3 60゚ 11 12 12 3.5 5.5
 FV-10A(S) 254 345 325 272 42 146 M10-4 φ11-4 45゚ 15 12 15 5.0 9
 FV-12A(S) 305 410 390 304.5 45 172 M10-4 φ11-4 45゚ 16.5 12 16.5 8.0 13
Notes:  The "A"and "S"at the end of the model numbers indicate aluminum and stainless steel, respectively.
  The pressure exerted on the valve by the powdered material must be 0.014 MPa or less.
  •
